4G LTE M2M IOT Industial edge router
| CELLULAR WAN | • Supported Frequency Bands -- LTE: B1, B2, B3, B4, B5, B7, B8, B20, B28 -- WCDMA: 2100(B1), 1900(B2), 850(B5) -- EV-DO/CDMA: 800(BC0) -- GSM/GPRS/EDGE: 850/900/1800/1900 • Automatic SIM based network operator switching |
| HOST INTERFACES | • 10/100/1000 Base-T RJ45 Ethernet port • (1)RS-232 ,(5)RS-485 Serial Console Port • 4 SMA antenna connectors (WIFI and Double-cellular) • (6) pin,(14)pin 3.5mm terminal block |
| INPUT/OUTPUT | • (6) pin 3.5mm terminal block. • (2) DI, (1) DO, (1) Relay. • Input ON Voltage: 5 to 30 VDC. • Input OFF Voltage: 0 to 3 VDC. • Output < 50mA @ 30VDC. • Relay:1A 250VAC/30VDC |
| LAN | • DNS, DNS Proxy • DHCP Server • IP Passthrough (option) • VLAN • Host Interface Watchdog • PPPoE |
